Refer to the cam profile image above for measurements listed:
324°= Oez: duration of valve lift, degree crankshaft
106 = Spr: distance lobe centerline, degree camshaft
Valve time:
88 = AO: exhaust opens, degree crankshaft before BOC
56 = AS: exhaust closes, degree crankshaft after TDC
56 = EO: inllet opens, degree crankshaft before TDC
88 = ES: inllet closes,. degree crankshaft after BOC
YES = NV: N means: following information is for cam lift
NO = V means: following intonation is for valve lift
7.70 = Hub: cam lift or valve lift, mm
YES = MH: M means: for mechanical valve clearance
NO = H means: for hydraulic valve clearance
3.1 = HoT: cam lift or valve lift at TDC, mm
Gkd: diameter of base circle, mm
A = Exhaust
E = lntake
