Refer to the cam profile image above for measurements listed:
332°= Oez: duration of valve lift, degree crankshaft
100 = Spr: distance lobe centerline, degree camshaft
Valve time:
86 = AO: exhaust opens, degree crankshaft before BOC
66 = AS: exhaust closes, degree crankshaft after TDC
66 = EO: inllet opens, degree crankshaft before TDC
86 = ES: inllet closes,. degree crankshaft after BOC
YES = NV: N means: following information is for cam lift
NO = V means: following intonation is for valve lift
7.68 = Hub: cam lift or valve lift, mm
YES = MH: M means: for mechanical valve clearance
NO = H means: for hydraulic valve clearance
3.7 = HoT: cam lift or valve lift at TDC, mm
Gkd: diameter of base circle, mm
A = Exhaust
E = lntake
